Switchcraft And WD Custom 3 Position Short Frame Toggle Switch

Switchcraft® And WD® Custom 3 Position Short Frame Toggle Switch

This short frame Switchcraft® straight toggle switch is a blend between the long WDE7SW for Les Paul® guitars and the right angle WDE6SW used in SG's® and is used either where body thickness will not accomodate the longer switch or where a more compact switch design is desired. This special switch was designed by WD Music Products®' VP Larry Davis and built by Switchcraft® as a high quality alternative to existing short frame switches.

Electrical:

• Contact Ratings: Fine silver contacts rated at 3A, 300W maximum AC non-inductive load standard.
• Leakage Resistance: 1,000 MW or greater
• Dielectric Strength: 250 VDC

Materials:

• Frame: Steel, plated
• Bushing and Shaft: Copper alloy, plated
• Springs: Copper alloy
• Knob: Molded thermoplastic
• Mounting Hardware: Knurled copper alloy locknut T10711, supplied
• Insulation: Rigid plastic spacers with plastic tubing through stack. Rigid plastic and/or thermoplastic lifters. Thermoplastic cam on actuator end

[SKU:WDE7SWS-1]

• Depth required = 15/16 in.
• Threaded bushing length = 3/8 in.
• Pre-tinned for soldering
